SPECIFICATIONS





Model Number: 36V 48V 52V Ebike Battery

Size: 270*138*70mm/ 10.6*5.5*2.8inch

Application: ebike

Weight: About 4.7kg/10.36lbs

Nominal Capacity: 8AH 10AH 14AHH 16AH 20AH 30AH

Type: Li-Ion

Voltage: 36V 48V 52V

Battery model: 48V 20Ah scooter battery

Connectors Type: T-plug/XT60/XT90 Connector

Charge Cutoff Voltage (V): 54V+/-1V

Charger: include in package

Maximum Continuous Discharge Current (A): 30Amp 35Amp

Automatic Low Voltage Disconnect: 25V

Automatic Short Circuit Protection: Instant

Automatic Over Voltage Protection: 58V

Cell Type: 18650B/ Panasonic 21700/ LG 21700

Discharge Temperature: -20℃ to 65℃

Charge Temperature: 0 to 45℃

Discharging Temperature Range: -20°C~70°C/-4 ~ 158°F

Storage Temperature Range: 0°C ~ 30°C /32 ~ 86°F

Rated Discharge Current (A): 30A

Instantaneous Maximum Discharge Current (A): 50A

Continuous Discharge Current (A): 30A

Standard Charge Current (A): 2A

Charge Time under Standard Charge Current: 6h

Fast Charge Current (A): 4A/5A

Charge Time under Fast Charge Current: 3hours to 3.5hours

Charge Temperature Range: 0-55°C/32-131°F

Cell Size (L*W*T ): 275*142*70mm/ 10.83*5.59*2.76inch

Battery Weight: About 4.8kg/10.36lbs

Compatible Model: For all 48V ≤1200Watt Electric Bicycle Hub Kit
